| Coil Post-Processing Process Items | Flat Coils | Tips |
|---|---|---|
| Material | 200°C~220°C enameled copper wire, enameled aluminum wire, bare copper wire, bare aluminum wire, etc. (flat wire) | Use 200~220 grade flat wire for good temperature resistance |
| Wire Thickness (mm) | 0.05~6.0 | The maximum width-to-thickness ratio for windable wire is 30 times |
| Wire Width (mm) | 0.6~20.0 | / |
| Cross-Sectional Area (mm²) | 0.1~60mm² | / |
| Winding Method | Vertical winding, horizontal winding, bifilar winding, figure-8 winding | / |
| Winding Direction | Clockwise winding, counterclockwise winding | / |
| Coil Inner Hole Shape | Round, rectangular, racetrack, triangular, trapezoidal | / |
| Coil Post-Processing Process | Winding, pin bending, enamel stripping, soldering, drilling, pin flattening, riveting, welding, tapping, etc. | The inner hole diameter must be at least 1.5 times the wire width |
| Coil Height (Turns) | ≤95mm (0.75~200 Turns) | ≤95mm (0.75~200 Turns) Height = Wire Thickness (T) × Gap Coefficient (Coef) × Number of Turns (Ts) |
