Compatibility range
Magnetic ring outer diameter 22/80, wire diameter within 3.5, any length, as long as the inner hole supports. Common mode, differential mode, three-phase, four-phase, disc-shaped, multi-wire parallel winding products, and spring wires can all be made.
Machine dimensions: length 70cm, width 36cm, height 95cm, weight 60kg.
Standard Functional Features
Possesses all the functions of touch-controlled semi-automatic models.
Exclusive Feature Highlights
1. Precise Lap Counting: Building on traditional lap counting (where any hook movement counts as a lap, regardless of whether the thread is caught), it adds a precise lap counting feature. A missed thread will not be counted, the magnetic ring will not rotate, and it will wait for manual re-threading before continuing to count and rotate. This effectively solves the problem of inaccurate manual lap counting, saving effort and improving efficiency.
2. Automatic rewinding: By setting the skip layer angle through software parameters, automatic rewinding can be achieved, saving the manual time of traditionally rotating the magnetic ring, thus saving time and improving efficiency.
3. Safety Protection: Multiple safety protections, including protective plates, exclusively customized safety light grids, and software protection programs, ensure the safety of operators.
