Solenoid valve coils, switching power supply coils, relay coils, ignition coils, and other skeleton-type coils that do not require encapsulation.
Suitable for high-precision, high-volume winding and tape wrapping of standard skeleton coils.
1. Motion Controller: 6-axis CNC precision control system
2. Solenoid Valve: SMC
3. Servo Motor: Fuji/Panasonic (Japan)
4. Guide Rail, Ball Screw: TBI/THK (Taiwan)
5. Cylinder: SMC/Airtac
| Number of Spindles | 6 |
| Spindle Pitch | 92mm |
| Spindle Speed | 12000 rpm |
| Spindle Servo Motor | 750W/1500W |
| Optional | X:400W Y:400W Z:400W A:400W |
| Spindle Quick Clamp Inner Diameter | Standard 8mm, Special 10mm |
| Wire Diameter Range | Φ0.02-Φ1.2 (Φ>1.2) |
| Optional | Wire diameter above Φ0.4 requires additional accessories |
| Max Winding Skeleton Outer Diameter | 85mm |
| Guide Needle Travel Range | X: 110mm Y: 108mm Z: 120mm A: 100mm |
| Spindle Positioning Accuracy | ±0.1° |
| Movement Positioning Accuracy | 0.01mm |
| Winding Angle | Standard 0°, 90° |
| Control System | 6-axis CNC precision software control |
| Air Pressure | 0.5-0.65MPa |
| Power Supply Voltage | AC220V/50Hz (AC110V/60Hz) |
| Total Power | 2000W/2700W |
| Machine Weight | 600Kg |
| Machine Dimensions | 1200L x 900W x 1500H |
| Optional Pneumatic Cutter | Simple cutter, automatic tape wrapping device, dual-wire parallel winding, four-wire parallel winding. |
